Additional Information Part Number CSC1-20 Features Versatile Can be used with any DC motor control. Hysteresis Time Delay Maximum Relay Current 0.5 amps @ 120 VAC, 1.0 amp @ 30 VDC Offset OFFSET Range 50% - 150% of set point HYSTERESIS Range: 50% -...

Additional Information Part Number CSC1-30 Features Maximum Relay Current 0.5 amps @ 120 VAC, 1.0 amp @ 30 VDC Offset TIME DELAY Range 0.2 to 15 seconds Maximum Relay Voltage: 125 VAC, 110 VDC Set Points 1, 2.5, 5, 10, 15, 20 amps OFFSET...

Additional Information Part Number CSC1-5 Features Set Points 0.25, 0.5, 1, 2, 3, 4 amps Versatile Can be used with any DC motor control. Hysteresis Time Delay OFFSET Range 50% - 150% of set point HYSTERESIS Range: 50% - 98% of set point Diagnostic...

Additional Information Part Number DC1.5-12 Features Compact footprint Fits in places where you never though a drive could. Custom round PCB's are available to mount directly on the back of a motor -0964 Spec models ending in -0964 allow for the connection of a...

Additional Information Part Number DC1.5-24 Features -0964 Spec models ending in -0964 allow for the connection of a remote speed potentiometer, replacing the SPEED trim pot on the board. Low Voltage motor operation Designed for 12 and 24 VDC motors. Compact footprint Fits in...

Additional Information Part Number DC120-12/24-4Q Features Stopping modes Brake (N.O.) or coast (N.O.) to a stop. RoHS All DC6-4Q and DC20-4Q series models are RoHS compliant. High continuous current Up to 60,100, or 120 amps continuous, robust bus bars used to handle the current....

Additional Information Part Number DC16-12/24 Features Diagnostic LEDs Power.Stopping modes: The user can coast the motor to a stop (N.O.). DC input voltage Accepts DC input and outputs DC voltage up to 95% of the input with near perfect form factor. Speed range and...

Additional Information Part Number DC2.0-12 Features Microprocessor based design Allows quick turnaround for custom units. Cage clamp terminal block Quick and easy wire terminations reduce installation time User adjustable calibration pots Speed and Current Limit. Ideal for battery powered equipment Maintains both set and/or...

Additional Information Part Number DC20-12/24-4Q Features Microprocessor based Allows for special calibration ranges or custom I/O for OEMs. DC6-12/24-4Q allows for unidirectional or bidirectional; control with the unidirectional signal. Ask about custom programming for positioning cycling, Deceleration, IR Comp. User adjustable calibration Minimum Speed,...

Additional Information Part Number DC240-36/48-4Q Features Fan Accessory Optional field install-able fan kit increases continuous current rating at 160 Amps. Four Quadrant Control Simple reversing and braking via a switch closure to the drive. On Board Calibration Calibrate using on board non-interactive trimmer pots,...

Additional Information Part Number DC250-12/24-4Q Features Four Quandrant Control Simplereversing and braking via a switch closure to the drive. Max One Min. Peak Current 240 Amps. 1.01 Form Factor Clean DC output for effiecient and quiet motor operation at a 16 kHz PWM frequency....

Additional Information Part Number DC30-12/24-4Q Features RoHS All DC30-12/24-4Q series models are RoHS compliant. Low Voltage motor operation Designed for 12 and 24 VDC motors. Speed range, regulation, & form factor 1% of base speed regulation with 100:1 speed range and a 1.01 form...

Additional Information Part Number DC30-12/24-4Q-W Features Speed range, regulation, & form factor 1% of base speed regulation with 100:1 speed range and a 1.01 form factor over the entire range. Stopping modes Brake or coast to a stop. Low Voltage motor operation Designed for...

Additional Information Part Number DC6-12/24 Features Microprocessor based design Allows quick turnaround for custom units. Reverse polarity protection The drive is not damaged when connected to the battery or power supply backwards. User adjustable calibration pots Speed and Current Limit. Cage clamp terminal block...

Additional Information Part Number DC6-12/24-4Q Features Microprocessor Based Allows custom programming for OEMs 1.01 Form Factor 1% Base Speed Regulation Reverse Maximum Speed Minimum Speed 4Q Reversing Regenerative / 4-Quadrant drives have the ability to perform quick and contactorless braking and/or reversing-on-the-fly Wig-Wag Mode...

Additional Information Part Number DC6-36/48-4Q Features 10001 Speed Range Forward Maximum Speed Diagnostic LEDs Power, Status(Current Limit, Undervoltage, Overvoltage, Overheat Foldback) Motor Current Limit Regen Current Limit Microprocessor Based Allows custom programming for OEMs 4Q Reversing Regenerative / 4-Quadrant drives have the ability to...

Additional Information Part Number DC60-12/24 Features DC input voltage Accepts DC input and outputs DC voltage up to 95% of the input with near perfect form factor. Additional features Inhibit terminals (P/N 201-0024 for plug assembly), extruded chassis and non-interactive trimmer pots. Low voltage...

Additional Information Part Number DC60-12/24-4Q Features Brake Output Applies a voltage out to a brake coil when the drive is disabled or stopped. Speed range, regulation, & form factor 1% of base speed regulation with 80:1 speed range and a 1.01 form factor over...

Additional Information Part Number DC60-36/48 Features One drive for two motor voltages On board jumper to select 12 or 24VDC motor (36 or 48VDC on some models). Low voltage motor operation Designed for 12, 24, 36 and 48VDC motors. DC input voltage Accepts DC...

Additional Information Part Number DC60-36/48-4Q Features Stopping modes Brake or coast to a stop. Low Voltage motor operation Designed for 12 and 24 VDC motors. User adjustable calibration Minimum Speed, Forward Maximum Speed, Reverse Maximum Speed, Motor Current Limit, Regen Current Limit, Acceleration, Deceleration,...

Additional Information Part Number DCL600-30-00MD Specifications Technology Type PWM Input Voltage 24 / 48 VDC Output Voltage 0 - 24 / 0 - 48 VDC Continuous Current 15 Amps Peak Current 30 Amps (1 Minute) Enclosure Chassis Braking Type Regenerative Reversing Type Regenerative Isolation...

Additional Information Part Number DLC600 Features 0.05% speed regulation of set speed provides for tight control throughout a 2001 speed range Selectable Feedback Devices: Makes specific application readouts easy Excellent Speed Regulation: Display can be set for wide variety of engineering measurements (ft/sec, gal/min,...

Additional Information Part Number EC2 Features MM Footprint and Compact Size Traditional MM mounting pattern with smaller footprint uses minimal space Current Limit IR Compensation 601 Speed Range Maximum Speed Low Cost Designed for cost savings in large quantities for OEMs Stopping Modes Inhibt...

Additional Information Part Number HTL05-D-4Q Features Microprocessor based Custom programming available for OEMs. True low voltage output Allows use of 115 or 230 VAC supply voltage on 12 or 24 VDC motors. All in one package Switching power supply and DC drive in one...

Additional Information Part Number HTL05-D-4Q-A Features Easy Calibration Trimpot adjustments for FWD ACCEL, REV ACCEL, FWD MAX SPD, REV MAX SPD, FWD CURR LIMIT, REV CURR LIMIT, IR COMP, and MIN SPD. Diagnostics LEDs for power and current limit status. Isolation Easy interface to...
